Mastering Design-For-Test

Mastering Design-For Test is a very thorough 4-hour Design-For-Test course offered about every three weeks, check the calendar for the next class offering.

This course will teach engineers, managers, and technicians how to maximize test coverage using state-of-the-art Test Equipment. Indeed, Mastering Design-For-Test will cover all major aspects of Test Engineering to achieve optimal designs for the test equipment, including:

.

• Automated Optical Inspection (AOI),
• Automatic X-Ray Inspection (AXI),
• Flying Probe Test (FPT)
• Boundary-Scan Test (B-S)
• In-Circuit Testing (ICT)
• Functional Card Testing (FCT).

In order to maximize synergy among the Design Engineer,the CAD Layout Engineer, and the Test Engineer, I encourage all interested parties to attend this training for a fixed price of $500. There is not a limit for the number of attendees from a single facility.

We have several platforms (Asset Intertech, Acculogic, etc.) to provide to perform stand-alone Functional Testing with Boundary-Scan test techniques.

Mastering Design-For-Test: Course Outline.

We can support functional test development with the whole Test Stand suite, with LabView, with LabWindows, et al.

Section I. Test Tutorial.

• Summary of Manufacturing process and "10X Theory" for Test Engineering.
• In-Circuit Test and Flying Probe Test tutorial.
• Boundary-Scan Test Tutorial.
• Test fixturing tutorial.

Section II: Design-For-Test.

1. Guidelines Access Design Guidelines.
• Guidelines to ensure 100% Guidelines access, included access to isolated nodes.
• Center-to-Center spacing and Test Point size guidelines.
• Power and Ground Guidelines access including Test Points for power-up.
• Review of cases where Guidelines access is not necessary.


2. Analog Device Design Guidelines.
• Designing discrete devices (such as resistors and capacitors) in such a way that they’re always testable.
• Implementing Kelvin ("4-Wire") Measurements.
• Guidelines for Polarized Caps, Batteries, and SuperCaps.
3. Digital Design Guidelines.
• Configuring control pins to attain maximum fault coverage.
• Programming devices at ICT / FPT.
• Design guidelines for crystals and oscillators.
• Designing in the ability to disable feedback loops.
4. Function Test Design Guidelines.
• Test Points and Eyelets for FCT debug and fault isolation.
• Using a Bed-Of-Nails for FCT.
• Booting of external PROMs.
5. Mechanical Design Guidelines.
• Standard sizes, shapes, and placements for Test Points for ICT and for FPT.
• Component height restrictions for ICT and FPT.
• Special design constraints for RF-based boards.
6. Panelized Board Design Guidelines.
• Placement of fiducials and tooling holes for boards and their panels.
• Guidelines for safely separating boards from their panels, especially when testing is placed before de-paneling.
7. Boundary-Scan & J-Tag Design Guidelines.
• Placement of a test connector for power-up, B-S pins, and compliance pins.
• Design rules for the Test Access Port pins.
• Understanding the trade-offs between chaining B-S devices and separating the B-S chains.
• Understanding the distinction between B-S and J-TAG.
• Designing memories for maximum testability using B-S.
8. Automated Optical and X-Ray Inspection (AOI & AXI) Guidelines.
• Placement of a white square under optional devices for AOI to quickly pick up the intentionally missing device.
• Making the spacing between IC pins to be a dark color to easily detect adjacent solder shorts.
